FLOAT DRUMS




  • ASTM D1998-06 Falling Dart Impact Test: Validates that virgin grade resin is being used and that the molding process is complete and properly done. When punctured, Ace Roto-Mold Float Drums do not crack or shatter.
  • 7-Day Hunt Water Absorption Test: Foam fill will aid in maintaining buoyancy if float becomes damaged. Properly steamed foam creates a tight seal which will prevent waterlogged floats and sinking docks. Void-free foam also supports outer shell walls, adding strength. Ace Roto-Mold Float Drums meet or exceed the test standard of 3 lbs per cubic foot.
  • Encasement Wall Thickness Standard: Eliminates weak wall floats with early failure potential and provides an insurance policy against unnecessary repair costs. Ensures floats will hold up to pre and post install abuse. Ace Roto-Mold Float drums have a nominal wall thickness of 0.150" and a minimum thickness of 0.125".
  • Tank Tested Buoyancy Ratings: Calibrated Tank Tested Buoyancy for each model unit is available.
  • US Army Corp of Engineers Regulation 33CFR Part 327.30: Ace Roto-Mold Float Drums meet or exceed the US Army Corp of Engineers standards under Regulation 33CFR Part 327.30.
  • 15-Year Float Drum Warranty: Ace Roto-Mold offers a 15-Year Float Drum Warranty on all of its manufactured float drums to the original owner.
  • Available in White: All floats also available in WHITE upon request for no additional charge.

FLOAT DRUMS
Model #
Size
Drum
Buoy
Weight
(lbs)
Specs

   Series 1248:
1248-20
12" X 48" X 20"
359
27
view
Add to Estimate
   Series 1848:
1848-36
18" X 48" X 36"
966
54
view
Add to Estimate
   Series 1872:
1872-16
18" X 72" X 16"
620
45
view
Add to Estimate
   Series 2072:
2072-08
20" X 72" X 8"
360
34
view
Add to Estimate
2072-10
20" X 72" X 10"
450
38
view
Add to Estimate
   Series 2096:
2096-10
20" X 96" X 10"
592
50
view
Add to Estimate
   Series 2323:
2323-24RND
23" X 24"
330
22
view
info
Add to Estimate
   Series 2436:
2436-08
24" X 36" X 8"
211
21
view
Add to Estimate
2436-12
24" X 36" X 12"
318
27
view
Add to Estimate
2436-16
24" X 36" X 16"
436
30
view
Add to Estimate
2436-20
24" X 36" X 20"
540
33
view
Add to Estimate
   Series 2448:
2448-08
24" X 48" X 8"
288
27
view
Add to Estimate
2448-12
24" X 48" X 12"
433
33
view
Add to Estimate
2448-16
24" X 48" X 16"
581
39
view
Add to Estimate
2448-20
24" X 48" X 20"
729
44
view
Add to Estimate
2448-24
24" X 48" X 24"
866
50
view
Add to Estimate
2448-36
24" X 48" X 36"
1297
72
view
Add to Estimate
   Series 2472:
2472-12
24" X 72" X 12"
629
44
view
Add to Estimate
2472-16
24" X 72" X 16"
796
57
view
Add to Estimate
   Series 2496:
2496-08
24" X 96" X 8"
562
53
view
Add to Estimate
2496-12
24" X 96" X 12"
866
64
view
Add to Estimate
2496-16
24" X 96" X 16"
1155
75
view
Add to Estimate
2496-20
24" X 96" X 20"
1420
84
view
Add to Estimate
   Series 3048:
3048-12
30" X 48" X 12"
514
33
view
Add to Estimate
3048-16
30" X 48" X 16"
712
38
view
Add to Estimate
   Series 3648:
3648-08
36" X 48" X 8"
429
37
view
Add to Estimate
3648-12
36" X 48" X 12"
650
45
view
Add to Estimate
3648-16
36" X 48" X 16"
874
51
view
Add to Estimate
3648-18
36" X 48" X 18"
990
54
view
Add to Estimate
3648-20
36" X 48" X 20"
1088
62
view
Add to Estimate
3648-24
36" X 48" X 24"
1280
66
view
Add to Estimate
3648-32
36" X 48" X 32"
1644
82
view
Add to Estimate
   Series 3660:
3660-12
36" X 60" X 12"
783
58
view
Add to Estimate
3660-16
36" X 60" X 16"
1017
61
view
Add to Estimate
3660-20
36" X 60" X 20"
1,328
74
view
Add to Estimate
   Series 3672:
3672-12
36" X 72" X 12"
999
62
view
Add to Estimate
3672-16
36" X 72" X 16"
1313
78
view
Add to Estimate
3672-20
36" X 72" X 20"
1638
87
view
Add to Estimate
3672-24
36" X 72" X 24"
1951
99
view
Add to Estimate
3672-32
36" X 72" X 32"
2553
120
view
Add to Estimate
   Series 3696:
3696-12
36" X 96" X 12"
1331
90
view
Add to Estimate
3696-16
36" X 96" X 16"
1735
103
view
Add to Estimate
3696-20
36" X 96" X 20"
2172
112
view
Add to Estimate
3696-24
36" X 96" X 24"
2597
132
view
Add to Estimate
3696-32
36" X 96" X 32"
3349
149
view
Add to Estimate
   Series 3878:
3878-12
38" X 78" X 12"
1133
76
n/a
Add to Estimate
   Series 4272:
4272-12
42" X 72" X 12"
1166
80
view
Add to Estimate
4272-16
42" X 72" X 16"
1555
86
view
Add to Estimate
4272-20
42" X 72" X 20"
1934
98
view
Add to Estimate
   Series 4848:
4848-12
48" X 48" X 12"
878
55
view
Add to Estimate
4848-16
48" X 48" X 16"
1182
67
view
Add to Estimate
4848-20
48" X 48" X 20"
1480
77
view
Add to Estimate
4848-24
48" X 48" X 24"
1738
86
view
Add to Estimate
4848-32
48" X 48" X 32"
2231
108
view
Add to Estimate
4848-36
48" X 48" X 36"
2480
114
view
Add to Estimate
   Series 4860:
4860-12
48" X 60" X 12"
1101
73
view
Add to Estimate
4860-16
48" X 60" X 16"
1497
80
view
Add to Estimate
4860-20
48" X 60" X 20"
1851
92
view
Add to Estimate
4860-24
48" X 60" X 24"
2199
106
view
Add to Estimate
4860-32
48" X 60" X 32"
2815
130
view
Add to Estimate
   Series 4872:
4872-12
48" X 72" X 12"
1369
78
view
Add to Estimate
4872-16
48" X 72" X 16"
1823
98
view
Add to Estimate
4872-20
48" X 72" X 20"
2225
111
view
Add to Estimate
4872-24
48" X 72" X 24"
2701
123
view
Add to Estimate
4872-28
48" X 72" X 28"
2940
141
view
Add to Estimate
4872-32
48" X 72" X 32"
3457
154
view
Add to Estimate
4872-36
48" X 72" X 36"
3800
166
view
Add to Estimate
   Series 4884:
4884-12
48" X 84" X 12"
1510
89
view
Add to Estimate
4884-16
48" X 84" X 16"
2056
105
view
Add to Estimate
   Series 4896:
4896-12
48" X 96" X 12"
1803
109
view
Add to Estimate
4896-16
48" X 96" X 16"
2396
131
view
Add to Estimate
4896-20
48" X 96" X 20"
2996
145
view
Add to Estimate
4896-24
48" X 96" X 24"
3578
163
view
Add to Estimate
4896-32
48" X 96" X 32"
4631
193
view
Add to Estimate
   Series 48120:
48120-12
48" X 120" X 12"
2118
124
view
Add to Estimate
48120-16
48" X 120" X 16"
3020
143
view
Add to Estimate
48120-20
48" X 120" X 20"
3692
177
view
Add to Estimate
